Typical Applications

Residential Solar Power Systems - Ideal for homes to provide backup power during outages or energy-saving operations.
Telecommunication Base Stations - Can be used to power remote telecom equipment, ensuring uninterrupted connectivity.
Small Business Operations - Suitable for offices, shops, or small businesses needing reliable off-grid power solutions.
Rural Electrification Projects - Perfect for areas without grid access, powering basic household and community needs.
Emergency Power Backup Systems - Essential for hospitals, schools, or emergency centers to ensure critical power supply.

Features

Pure sine wave solar inverter
Built-in 40A MPPT solar charger
PV input voltage range 20-1 SOVDC (for 1OOOW),30~150VDC(for 1500W)
Built-in anti-dust kit for harsh environment
Smart battery charge design to optimize battery life
Meet rich customized demands
Solar energy is provided directly to the load first

Technical Data

PARAMETER	SMS-1000-12	SMS-1500-24
GENERAL
Rated Power	1000 W / 1000 VA	1500 W / 1500 VA
Battery System Voltage	12 VDC	24 VDC
AC INPUT
Nominal Input Voltage	230 VAC	230 VAC
Selectable Input Range — Computer Loads	170 – 280 VAC	170 – 280 VAC
Selectable Input Range — Appliance Loads	90 – 280 VAC	90 – 280 VAC
Input Frequency Range	50 Hz / 60 Hz (auto sensing)	50 Hz / 60 Hz (auto sensing)
AC OUTPUT
Output Voltage Regulation	230 VAC ± 5 %	230 VAC ± 5 %
Output Waveform	Pure sine wave	Pure sine wave
Output Frequency	50 Hz / 60 Hz	50 Hz / 60 Hz
Surge Power (20 ms)	2000 VA	3000 VA
Peak Efficiency — PV to Inverter	98 %	98 %
Peak Efficiency — Battery to Inverter	94 %	94 %
Transfer Time	10 ms	10 ms
BATTERY & CHARGER
Nominal Battery Voltage	12 VDC	24 VDC
Float Charge Voltage	13.5 VDC	27.0 VDC
Overcharge Protection	16.0 VDC	32.0 VDC
Maximum AC Charging Current	40 A	40 A
SOLAR CHARGER (MPPT)
Solar Charger Type	MPPT	MPPT
Maximum PV Array Power	600 W	1200 W
MPPT Operating Voltage Range	20 – 150 VDC	30 – 150 VDC
Maximum PV Open-Circuit Voltage (Voc)	150 VDC	150 VDC
Maximum Solar Charging Current	40 A	40 A
Maximum Solar + AC Charging Current	80 A	80 A
MECHANICAL
Dimensions (H × W × D)	290 × 240 × 91 mm	290 × 240 × 91 mm
Carton Dimensions (H × W × D)	340 × 295 × 145 mm	340 × 295 × 145 mm
Net Weight	3.5 kg	3.6 kg
Gross Weight	4.0 kg	4.2 kg
Mounting	Wall-mounted	Wall-mounted
BATTERY BANK CONFIGURATION — BATTERIES ONLY, NOT SOLAR PANELS¹
Battery Modules in Series	Not permitted — parallel connection only	Not permitted — parallel connection only
Compatible SATTE Lithium Battery	SH-UIB-P12100 / P12150 / P12200 (12.8 V)	S200Ah, 24 V 200 Ah (4.8 kWh)
Max. Battery Modules in Parallel	2	1
Recommended Battery Bank Capacity	1.3 – 2.6 kWh	4.8 – 7.2 kWh
DISPLAY & MONITORING
Display	LCD with status and fault indication	LCD with status and fault indication
Remote Monitoring (Wi-Fi / app)	Not available on this model. Specify SATTE SML or SNM-ECO where app monitoring is required.	Not available on this model. Specify SATTE SML or SNM-ECO where app monitoring is required.
ENVIRONMENT & COMPLIANCE
Operating Temperature	−10 °C to +50 °C	−10 °C to +50 °C
Relative Humidity	5 % to 95 %, non-condensing	5 % to 95 %, non-condensing
Cooling	Forced air	Forced air
Compliance / Safety Mark	CE	CE
