SOLUTIONS

5SSP 25

5SSP 25
5SSP 255ssp_25


The add to cart button will appear once you select the values above

Typical Applications

  • Clean water pumping
  • Well pumping
  • River pumping
  • Farm irrigation
  • Water supply systems
  • Mining operations
  • Drainage in breeding industry

Operating Conditions

  • Water temperature up to 35°C
  • Ambient temperature permissible up to 40°C
  • 5SSP Minimum internal diameter of well: 5"(130mm)
  • Maximum sand content: 0.25%
  • Maximum immersion depth: 80m

Motor

  • Rewindable motor
  • Insulation Class B
  • Protection Ip68
    Speed RPM -2850

Technical Data

Model
Supply
 Motor P2 Current at 50 Hz (A)
Stages
Max. head (m)
Max. flow (m³/h)
Outlet
 Dimensions (mm)
Weight (kg)
kW HP Operating In Starting Ist Ø D P M T
5SSP 25-9 380-415 V 7.5 10 17.7 80 9 99 40 2", 2½" — — 770 — —
5SSP 25-13 380-415 V 11 15 24.9 112 13 143 40 2", 2½" — — 880 — —
5SSP 25-17 380-415 V 15 20 33.9 153 17 187 40 2", 2½" — — 980 — —



Product Videos

Datasheet/Downloads 5SSP 25 Datasheet
