SSWP

SSWP
SSWPSSWP


The add to cart button will appear once you select the values above

Typical Applications

  • For water supply from wells or reservoirs
  • For domestic use, for civil and industrial application
  • For Garden use and irrigation

Operating Conditions

  • Maximum fluid temperature up to +35°
  • Maximum sand content:0.15%
  • Minimum well diameter:130mm

Motor and Pump

  • Renewable motor
  • Single-phase:220V/50Hz
  • Three-Phase:380V/50Hz
  • Equip with start control box or digital auto-control box
  • It's available to equip with floating switch
  • Curve tolerance according to ISO 9906101
  • Enclosure Class: X8
  • Insulation Class: B
  • Voltage: 1x240V
  • Speed: 2900rpm

Technical Data

Model Motor Max
Particl
e Size,
mm		 Voltage
(V)		 Max
Current
(A)		 Outlet
(")		 Dimension
s (mm)		 Weight
(kg)
KW HP H W
SSWP 600 0.55 0.75 1 1x240 4.3 538 538 128 15
SSWP 10OO 0.92 1.25 1x240 6.2 577 577 18
SSWP 11OO 1.1 1.5   1x240
SSWP 1300 1.3 1.75 1.5 1x240 7.6 577 621 21
SSWP 1500 1.5 2 1 1x240 8.7 577 621 26



Product Videos

Datasheet/Downloads SSWP Datasheet
