Typical Applications

  • Automotive Industry: Pumps are used in the cooling systems of engines, ensuring efficient temperature control and preventing
    overheating during vehicle operation.
  • Drinking Water Treatment: Pumps help transfer and purify raw water to produce safe and potable water, essential for public
    health and sanitation.
  • Family Homes: Pumps provide a reliable water supply for daily household needs like drinking, cooking, cleaning, and
    gardening.
  • Metal and Equipment Manufacturers: Pumps are used for cooling machinery and transferring liquids, essential in industrial
    processes like metal cutting and lubrication.

Motor

  • Two-pole induction motor(n=2850 r.p.m)
  • Insulation Class B
  • Protection IP68
  • Continuous service S1
  • Thermal protector for single phase

Operating Conditions

  • 5m maximum immersion depth
  • Liquid temperature up to 35℃
  • Maximum ambient temperature 40℃
Component Construction
Pump body Cast iron
Suction filter Cast iron
Impeller Cast iron
Motor Shaft AISI304 SS
Mechanical Seal Alloy/Ceramic-Graphite
Cable

8m power cable

Technical Data

Model
 Motor
Voltage
 Current (A)
m
m³/h
rpm
Inch
kg
mm
kW HP In Ist
SWWHP 15G 3 4 3~ 380-415 V 6.3 28 34 18 2850 2" 48.5 305x255x625
SWWHP 30J 4 5.5 3~ 380-415 V 8.2 37 31.5 36 2850 3" 66.5 365x265x675
SWWHP 30L 5.5 7.5 3~ 380-415 V 11.1 50 38 36 2850 3" 73 365x265x705
SWWHP 100Q 7.5 10 3~ 380-415 V 14.9 67 21 120 2850 6" 103 410x320x765



Product Videos

Datasheet/Downloads SWWHP Datasheet
