The add to cart button will appear once you select the values above

Typical Applications


  • Off-gridborehole water supply where mains power is unavailable.
  • Drip, sprinkler and furrow irrigation on farms and smallholdings.
  • Rural and institutional supply — schools, clinics, trading centres. Livestock watering points and cattle troughs.
  • Filling elevated storage tanks for gravity distribution.
  • Emergency and temporary supply in relief operations.

Operating Conditions

  • Non-corrosive water; the volume ratio al sand content no more than 3%; particle size less than Imm
  • Max medium temperature up to +40°C; PH value remains 5-10
  • Work close to the rated head and must be immersed in water.

Technical Data

SATTE Model Rated Power (W) Motor (VDC) Rated Current (A) Stages Maximum Flow Maximum Head Outlet DN MPPT Controller Max Input (VDC) Array Vmp Window (V) Weight (kg)
m³/h l/min US gpm Imp gpm m ft
SD E400 400 48 9.1 3 5.4 90 23.8 19.8 42 138 1" DC48-VMP72 96 55–96 17
SD E600 600 48 13.6 4 5.4 90 23.8 19.8 58 190 1" DC48-VMP72 96 55–96 19
SD E800 800 48 18.1 5 5.4 90 23.8 19.8 72 236 1.25" DC48-VMP72 96 55–96 21
SD E1000 1000 72 15.1 7 5.4 90 23.8 19.8 105 344 1.25" DC72-VMP108 150 82–150 24



Product Videos

Datasheet/Downloads SFLO SD Datasheet
